Setup Docker Swarm Single node Cluster on Raspberry Pi

6 minute read

Description

In the previous chapter we learnt how to install Docker engine. Now in this chapter we will learn how to install Swarm mode.

First upall let us setup a single node Sawrm Cluster. We will see how Swarm mode works and we will understand few components of it. Then in our next chapter we will add 2 more nodes to our cluster. Asuming that we have already installed Docker Engine on our instance I will directly start creating the Swarm Mode.

Install Swarm mode

To create the Swarm you need to first SSH to the host machine where the Docker engine is installed. In my case I will SSH to the machine which IP is 192.168.0.131


Using username "pi".
pi@192.168.0.131's password:
Linux raspberrypi 4.19.97-v7l+ #1294 SMP Thu Jan 30 13:21:14 GMT 2020 armv7l

The programs included with the Debian GNU/Linux system are free software;
the exact distribution terms for each program are described in the
individual files in /usr/share/doc/*/copyright.

Debian GNU/Linux comes with ABSOLUTELY NO WARRANTY, to the extent
permitted by applicable law.
Last login: Mon May 18 19:08:22 2020 from 192.168.0.102
pi@raspberrypi:~ $

Run the following command on the hostmachine to start a new swarm:

pi@raspberrypi:~ $ docker swarm init
Swarm initialized: current node (jdu8ge8rafvdsiu9x9nhvhymp) is now a manager.

To add a worker to this swarm, run the following command:

    docker swarm join --token SWMTKN-1-0490adm0y5alpu48ydophj3b4lms61bkgofa0l9rcvuar0iyjf-4wturco6v3tddcq1fvtgt8v8a 192.168.0.131:2377

To add a manager to this swarm, run 'docker swarm join-token manager' and follow the instructions.

pi@raspberrypi:~ $

If you have more than one IP attached to your machine then you need to specify --advertise-addr

Run the below mentioned node ls command to list all available nodes.

pi@raspberrypi:~ $ docker node ls
ID                            HOSTNAME            STATUS              AVAILABILITY        MANAGER STATUS      ENGINE VERSION
jdu8ge8rafvdsiu9x9nhvhymp *   raspberrypi         Ready               Active              Leader              19.03.8
pi@raspberrypi:~ $

Now we can see one node which is basically a Leader, is in activie state and it’s stastus is ready. On the machine we have installed the Docker engine and on top of that we have created a Swarm mode. Now we can either choose the Docker engine to run our container or we can run our container inside our Docker Swarm. Lets start and run a container inside our swarm. To run a container inside the swarm normal docker run command won’t work. This will start the container in the Docker engine itself. To start a container inside the swarm we have use the command docker service.

Deploy service to Swarm

Run the command mentioned below to start/ run a nginx container inside swarm as web service.

pi@raspberrypi:~ $ docker service create --name web --publish 8080:80 nginx
htlom33no80y56f5zcyqwx6ak
overall progress: 1 out of 1 tasks
1/1: running   [==================================================>]
verify: Service converged
pi@raspberrypi:~ $

Here we are asking docker to create a service named as web. Publish the container port 80 to host port 8080. Use nginx image for the container. Now run the bellow command to list our serices.

pi@raspberrypi:~ $ docker service ls
ID                  NAME                MODE                REPLICAS            IMAGE               PORTS
htlom33no80y        web                 replicated          1/1                 nginx:latest        *:8080->80/tcp
pi@raspberrypi:~ $

You can see now we have a service running inside our Swarm. Let’s run the below command to see the running task of the service.

pi@raspberrypi:~ $ docker service ps web
ID                  NAME                IMAGE               NODE                DESIRED STATE       CURRENT STATE           ERROR               PORTS
jn3cdf50h5yy        web.1               nginx:latest        raspberrypi         Running             Running 8 minutes ago
pi@raspberrypi:~ $

Cool, we can see one task is running for the service web named web.1.

Scale the service on Swarm

To increase the number of instance/ task for the service use bellow command:

pi@raspberrypi:~ $ docker service update --replicas 3 web
web
overall progress: 3 out of 3 tasks
1/3: running   [==================================================>]
2/3: running   [==================================================>]
3/3: running   [==================================================>]
verify: Service converged
pi@raspberrypi:~ $

Let us see the output of the command docker ps.

pi@raspberrypi:~ $ docker service ps web
ID                  NAME                IMAGE               NODE                DESIRED STATE       CURRENT STATE            ERROR               PORTS
jn3cdf50h5yy        web.1               nginx:latest        raspberrypi         Running             Running 16 minutes ago
yzlqjru481db        web.2               nginx:latest        raspberrypi         Running             Running 2 minutes ago
nb7a6w2lgvzb        web.3               nginx:latest        raspberrypi         Running             Running 2 minutes ago
pi@raspberrypi:~ $

WoW!! Now we can see three task are running for the service web. Now let’s do some nasty thing to our service. Let’s kill one conrainter using docker stop command and see what is happening to our service inside the swarm.

pi@raspberrypi:~ $ docker ps -a
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS              PORTS               NAMES
6893a035fbb8        nginx:latest        "nginx -g 'daemon of…"   5 minutes ago       Up 5 minutes        80/tcp              web.2.yzlqjru481dblmddeijz1o70c
3980624ded92        nginx:latest        "nginx -g 'daemon of…"   5 minutes ago       Up 5 minutes        80/tcp              web.3.nb7a6w2lgvzby5o6fmmrwmok4
950638b3f7e8        nginx:latest        "nginx -g 'daemon of…"   20 minutes ago      Up 19 minutes       80/tcp              web.1.jn3cdf50h5yys8unst29dnmdj
pi@raspberrypi:~ $ docker stop 3980624ded92
3980624ded92
pi@raspberrypi:~ $ docker ps -a
CONTAINER ID        IMAGE               COMMAND                  CREATED             STATUS                     PORTS               NAMES
6d4b447aa0ac        nginx:latest        "nginx -g 'daemon of…"   4 seconds ago       Created                                        web.3.x8b2bp33rklh93fmjqsgvvi1l
6893a035fbb8        nginx:latest        "nginx -g 'daemon of…"   6 minutes ago       Up 6 minutes               80/tcp              web.2.yzlqjru481dblmddeijz1o70c
3980624ded92        nginx:latest        "nginx -g 'daemon of…"   6 minutes ago       Exited (0) 5 seconds ago                       web.3.nb7a6w2lgvzby5o6fmmrwmok4
950638b3f7e8        nginx:latest        "nginx -g 'daemon of…"   20 minutes ago      Up 20 minutes              80/tcp              web.1.jn3cdf50h5yys8unst29dnmdj
pi@raspberrypi:~ $

As you see I just stopped the container 3980624ded92 which was belongs to the task web.1. Let’s list the service task again.

pi@raspberrypi:~ $ docker service ps web
ID                  NAME                IMAGE               NODE                DESIRED STATE       CURRENT STATE            ERROR               PORTS
jn3cdf50h5yy        web.1               nginx:latest        raspberrypi         Running             Running 23 minutes ago
yzlqjru481db        web.2               nginx:latest        raspberrypi         Running             Running 9 minutes ago
x8b2bp33rklh        web.3               nginx:latest        raspberrypi         Running             Running 3 minutes ago
nb7a6w2lgvzb         \_ web.3           nginx:latest        raspberrypi         Shutdown            Complete 3 minutes ago
pi@raspberrypi:~ $

Now we can see 4 entries for our service. But, the state of the last task is Shutdown. This proofs that Swarm keeps the history with it and helps us to make our application fault-tolerant.

In our next chapter we will add 2 more nodes to our Swarm mode to play with it.
